4088, Micros cravate et serre-tête de la marque DPA Microphones appartenant à la série d:fine.
Directional characteristics | Cardioid |
---|---|
Principle of operation | Pressure gradient |
Cartridge type | Pre-polarized condenser element with vertical diaphragm |
Frequency range, ± 2 dB | 100 Hz – 20 kHz (4 – 6 dB soft boost at 15 kHz) |
Sensitivity, nominal, ±3 dB at 1 kHz | 6 mV/Pa; 44 dB re. 1 V/Pa |
Equivalent noise level, A-weighted | Typ. 26 dB(A) re. 20 µPa (max. 28 dB(A)) |
Equivalent noise level ITU-R BS.468-4 | Typ. 38 dB (max. 40 dB) |
S/N ratio, re. 1 kHz at 1 Pa (94 dB SPL) | 68 dB (A) |
Total harmonic distortion (THD) | < 1 % up to 123 dB SPL peak; < 1 % up to 120 dB SPL RMS sine |
Dynamic range | Typ. 97 dB |
Max. SPL, peak before clipping | 144 dB |
Output impedance | 30 – 40 ohm |
Cable drive capability | Up to 300 m (984 ft) |
Power supply | For wireless systems: Min. 5 V – max. 50 V through DPA adapter. With DAD6001-BC/DAD6024/DAD4099: 48 V phantom power ±4 V for full performance. |
Connector | MicroDot |
Color | Black, brown or beige |
Microphone weight | 14 g (0.5 oz) incl. cable and MicroDot connector |
Microphone diameter | 5.5 mm (0.25 in) |
Microphone length | 11 mm (0.5 in) |
Cable length | 1.2 m (3.9 ft) |
Cable diameter | 1.6 mm (0.06 in) |
Polarity | Positively increasing sound pressure produces positive going voltage on MicroDot pin |
Operating temperature range | -10 to 45 °C (14 to 113 °F) |
Source : http://www.dpamicrophones.com/en/products.aspx?c=item&category=269&item=24062
Distribué par Audio 2
(119 avis) |
4088-DC-A-B00-LH | 695 € | ||
(97 avis) |
4088-DC-A-B00-LH | 695 € | ||
(481 avis) |
4088-dc-a-f00-lh Beige | 695 € | ||
(119 avis) |
4088-DC-A-F00-LH | 695 € | ||
(97 avis) |
4088-DC-A-F00-LH | 695 € |
![]() |
Micro Headset | 470 € | » |
![]() |
Vends 2 capsules Dpa 4088 | 900 € | » |
![]() |
2 DPA serre tête 4088 beige+adaptateur SHURE | 1 000 € | » |
![]() |
Micro DPA 4088 + Adaptateur XLR 48v | 450 € | » |
3 avis | 100 % |
3 personnes sur 3 ont trouvé cet avis utile
2 personnes n'ont pas trouvé cet avis utile
Autres dénominations : 40 88, 4088 Core
