Fiche technique
- Fabricant : TC Electronic
- Modèle : TC 1280
- Catégorie : Delay / échos
- Fiche créée le : 03/02/2009
|
Input/Output
|
|
Connectors
|
 |
XLR balanced (pin 2 hot)
|
|
|
Input Impedance (balanced)
|
|
20 kOhm
|
|
|
Max. Input Level (balanced)
|
|
+22 dBu
|
|
|
Input Gain adj.
|
|
+10/-10 dB
|
|
|
Output Impedance (balanced)
|
|
50 Ohm
|
|
|
Max. Output Level
|
|
+22 dBu
|
|
|
Output Gain adj.
|
|
0 to -70 dB
|
|
|
Dynamic Range
|
|
>100 dB
|
|
|
THD+N
|
|
<-66 dB(0.05%) @ 1 kHz, 0 dBu
|
|
|
Frequency Response
|
|
20 Hz to 20 kHz, +0.5/-0.5 dB
|
|
|
Group Delay
|
|
5 microseconds
|
|
|
Digital Conversion
|
|
Dynamic Differential 18 bit resolution AD/DA
|
|
|
Sample Rate
|
|
1 MHz
|
|
|
Processing Delay
|
|
30 microseconds
|
|
|
Control Interface
|
|
MIDI
|
|
In/Out: 5 Pin din, sysex Implemented
|
|
|
Remote
|
|
1/4 "phone jack
|
|
|
EMC
|
|
EMC Complies with
|
|
EN 55103-1, EN 55103-2, FCC Part 15 class B, CISPR 22 class B
|
|
|
Safety
|
|
Complies with
|
|
IEC 65, EN 60065
|
|
|
Environment
|
|
Operating Temperature
|
|
32° F to 122° F (0° C to 50° C)
|
|
|
Storage Temperature
|
|
-4° F to 140° F (-20° C to 60° C)
|
|
|
Finish
|
|
Anodized aluminum front
Plated cadium coating steel chassis |
|
|
General
|
|
Dimensions
|
|
1 3/4 x 19 x 11.6 inches (44x 482 x 294 mm)
|
|
|
Weight
|
|
11 lbs (5 kg)
|
|
|
Shipping Weight
|
|
14 lbs (6.4 kg)
|
|
|
Mains Voltage
|
|
100/120/220/240/ VAC, 50-60 Hz (selectable)
|
|
|
Power Consumption
|
|
30 W
|
|
|
Warranty
|
|
Parts and Labor
|
|
1 year
|
|
|
Options
|
|
ME80
|
|
Memory expansion card
|
|
|
CH01
|
|
1.25 sec. memory expansion
|
»
