Fiche technique
- Fabricant : Yorkville
- Modèle : TX8
- Catégorie : Autres enceintes de sono
- Fiche créée le : 08/09/2005
| System Type | 3-Way Trapezoid |
| Active or Passive | Passive |
| Biamp Operation Only | Yes |
| Sensitivity (dB @1Watt/1m) | HF:110, MF:109, LF:104 |
| Max SPL (dB) | 134 |
| Frequency Response (Hz +/- 3dB) | 60 - 19k |
| HF Driver(s) | 1 x 2 inch ceramic with titanium diaphragm |
| HF Program Power (Watts) | 120 |
| HF Impedance (Ohms) | 8 |
| HF Horn | Custom waveguide, phase plug coupled |
| HF Dispersion (°H x °V) | 60 x 40 |
| MF Driver(s) | 1 x 8 inch, cast frame |
| MF Program Power (Watts) | 100 |
| MF Impedance (Ohms) | 8 |
| MF Horn | Waveguide |
| MF Dispersion (°H x °V) | 60 x 30 |
| LF Driver(s) | 2 x 15 inch cast frame |
| LF Program Power(Watts) | 800 |
| LF Impedance (Ohms) | 4 |
| LF Horn | 90 degree hybrid manifold |
| Total Power (Watts) | 1020 |
| Inputs - Speakon 4-pin | 1 (subwoofer out) |
| Inputs - Speakon 8-pin | 2 |
| Bar Handles | 8 |
| Flying Hardware | ATM™ top, bottom and sides |
| Included Hardware | 17 inch flytrack, bar and quickpin slots |
| Optional Flying Hardware | SWIVELRING2, EYEBOLT3/8A |
| Enclosure Materials | 18mm / .71 inch - 13-ply baltic birch plywood |
| Grille | 16 gauge perforated metal |
| Covering / Finish | Black Ultrathane Paint |
| Processor (optional) | TX8P |
| Dimensions (DWH xbackW, inches) | 23.9 x 23.9 x 50 x 11.3 |
| Dimensions (DWH xbackW, cm) | 60.7 x 60.7 x 127 x 28.7 |
| Weight (lbs/kg) | 214.5 / 97.3 |
