Fiche technique
- Fabricant : Acoustic Energy
- Modèle : AE1 Classic
- Catégorie : Enceintes de monitoring passives
- Autres dénominations : ae1classic, ae 1 classic
Finishes:
Gloss Cherry Lacquer or Piano Black Lacquer
Bass/Mid Driver:
110mm ceramic sandwich aluminium cone. 32mm edge-wound voice-coil
Tweeter:
25mm magnesium alloy dome
Crossover:
Symmetrical third order at 3kHz
Power Handling:
Compatible with amplifiers rated at up to 200 Watts into 8 Ohms
Frequency Response:
70Hz - 22kHz ±3dB
Sensitivity:
86dB for 2.83V at 1m
Nominal Impedance:
8 Ohms
Total Harmonic Distortion:
Typically less than 0.3%, 200Hz to 20kHz
Power Compression:
Less than 1dB for 16dB gain at 250Hz
Dimensions (H x W x D):
295 x 180 x 255mm
Weight:
7.5kg (single, unpacked)
»
