Fiche technique
- Fabricant : dB Technologies
- Modèle : Opera 715 DX
- Série : Opera DX
- Catégorie : Enceintes de sono amplifiées
- Fiche créée le : 08/02/2013
System Specifications Frequency Response [-10dB] 49 - 20.000 Hz
Frequency Response [+/- 3dB] 59 - 19.000 Hz
Speaker Type 2-Way Active Speaker
Pole Mount Plate D36mm standard
Connections / Controls Input XLR (Input balanced) 1/4” Jack (Input/Link balanced)
Out XLR balanced (Link out) Input Sens. 2-way switch (Mic - Line)
Sensitivity Rotative knob Indicators 3x LEDs (LIMITER, SIGNAL, READY)
Mains VDE Socket Power On/Off switch EQ Preset 2-way switch (Flat - Processed)
HF 1”
Type HF Compression driver Voice Coil HF 1.4”
Max SPL 129 dB
Horn Asymmetrical
CD Horn Directivity 80°/65° x 60 °
Angles Up Monitor use 43 °
Housing Polyporpylen PP
Acoustical Data Amp Technology Digipro® G2 LF 15” Voice Coil LF 2”
Amplifier System Presets Flat, Processed Controller
DSP 24bit/48kHz
Power PRG 700 Watt Amp
Class D
Processor Limiter Dual Active Peak, RMS, Thermal X-over Frequency 1850 Hz, 24 dB/Oct.
Mechanics Depth 353 mm (13.90 in) Height 655 mm (25.79 in) Weight 15.4 kg (33.95 lbs.)
