The INTERVAL knob adjusts the time between discharges when the timer function is engaged. The range is from 10 seconds ~ 200 seconds.
The second knob labelled “VOLUME” controls the volume of haze produced.The range is from 0% ~ 100% of maximum output.
The yellow TIMER button controls the timer function. Depress the button to activate it. When activated the yellow light will turn on.
Adjusting the interval knob will determine the time between haze output (10~200 seconds). The duration of output is set at 13 seconds. The volume can be adjusted using the volume knob to control the amount of haze produced.
The red CONTINUOUS button sets the machine to constant haze production. To activate this function. depress the red button. The
volume knob can be used to regulate the volume of the steady stream of haze produced.
The green MANUAL button will produce a continuous blast at maximum volume while the button is held down.
When released, the manual function stops and the machine will return to the previous setting: timer, continuous, or stationary.
Note: the Continuous function will override the Timer function.
Therefore, if both buttons have been depressed, the Fogger will haze continuously.
The manual function overrides all functions.
When depressed and held down, the Fogger will haze at maximum volume for as long as the button is held down, regardless of the machine’s setting at the time.
