Vente Pittsburgh Modular Taiga

Description

B-Stock, Pittsburgh Modular Taiga; Semi-Modular Paraphonic Analog Synthesizer; fully analog signal path; 3 oscillators, each with manual controls for pitch, FM, shape (sine, triangle, sawtooth, square) and waveshaper/wavefolder; noise generator; 4-channel mixer; adjustable preamp with overdrive-circuit for external signals (gain: x30); LFO with two waveforms (triangle and square) and wide frequency-range (41s - 500Hz); multimode filter (lowpass, bandpass, highpass) with adjustable cutoff-frequency and resonance as well as 2 CV inputs with attenuators; 2 ADSR envelope-generators; Dynamics Controller with selectable VCA or Lowpass Gate mode and with adjustable frequency/bias, resonance and response; analog-delay with controllable delay-time, feedback and wet/dry mix; build-in MIDI-to-CV/Gate interface; further features: arpeggiator, random sequencer, clock divider, clock generator with tap-tempo, sample & hold, 2-channel mixer; CV inputs for all parameters and outputs for each section; line output and headphones output (3.5mm jack); can be used as a full featured Eurorack synthesizer voice (width: 60 HP, depth: 40mm); power consumption when used as a module: 650mA (+12V) / 475mA (-12V); dimensions of the desktop enclosure (WxDxH): 326 x 135 x 112 mm; weight: 1812g; included: external power supply, TRS-DIN MIDI adapter, x10 Nazca Noodles patch cables, B-Stock with full warranty, may have slight traces of use
