Vent 4 Scan Robe 250XT

Description

Spécifications Techniques
Source
•
Lamp: Compact high-pressure metal halide lamp
•
Base: GY9.5
•
Approved models: Osram HSD 250/80, Philips MSD 250/2, Sylvania BA 250/2 SE
•
Control: Automatic and remote on/off
•
Ballast: Magnetic
Système optique
•
Standard objective: 15°
•
Optional objectives: 12° and 18°
Spécifications électriques et connectique
•
Wiring options: EU model - 208/230/240V, 50/60Hz, US model - 100/120/208/230/240V, 50/60Hz
•
Power consumption: 500VA at 230V/50Hz
Spécifi cation mécanique
•
Height: 346 mm (13.6″) - bracket in horizontal position
•
Width: 306 mm (12.1″)
•
Depth: 629 mm (24.8″)
•
Weight: EU model - 16 kg (35.2 lbs), US model - 19 kg (41.9 lbs)
Spécifi cations thermiques
•
Maximum ambient temperature (Ta): 45°C (113°F)
•
Maximum surface temperature: 80°C (176°F)
Gobos rotatifs
•
Outside diameter - metal gobos: 26.9 mm
•
Outside diameter - dichroic and glass gobos: 26.8 mm
•
Thickness - metal gobos: 0.15 mm (steinless steel)
•
Thickness - dichroic gobos: 1.1 mm (high temperature borofl oat or better glass); glass gobos: max. thickness = 4mm (high temperature borofl oat or better glass)
