Fiche technique
- Fabricant : YannLu Audio
- Modèle : EQ500
- Catégorie : Egaliseurs paramétriques
- Autres dénominations : eq 500
This is the perfect replica of the EQ section from a Harrison MR console (early 80’s).
500-serie module
Proportional Q
High-Pass filter : 26 Hz to 2.2 kHz (12dB/oct)
Low frequency band : 40 Hz to 800 Hz – Bell or Shelf mode
Mid frequency band : 400 Hz to 8 kHz – 3 bell modes : Narrow / Standard / Wide
High frequency band : 800 Hz to 15 kHz – Bell or Shelf mode
Maximum 15 dB of boost/cut gain per band (center detent on 0 dB)
Bypass switch on each section
»
