Alto Professional TS312S

Features

• 2000 watts of peak power output
• High-efficiency Class D amplifier
• Transducer: 12-inch with 3-inch high-temperature voice coil
• (2) XLR+1/4-inch combo inputs + (2) balanced XLR line outputs
• XLR outputs, with six discreet output modes for ideal matching with companion speaker
• Polarity Reverse switch and Extended LF switch for increased EQ control
• Electronic clip, thermal and transducer overdrive protection
• Rugged, internally-braced front-ported MDF cabinet with integrated 36mm pole socket
• Rugged, mar-resistant splatter-spray finish always looks good, even with heavy use
• Designed and tuned in the USA

Technical Data

• Output Power: 2000 W peak, 1000 W continuous
• Amplifier: High-efficiency Class D amplifier
• Transducer: 12” (305 mm) woofer, 3” (76 mm) voice coil
• Frequency Response: 44HZ – 95Hz (- 3 dB)
• Frequency Range: 38Hz – 110Hz (-10 dB)
• Maximum SPL: 129 dB (@ 1 m) 126 dB continuous (dB SPL @ 1 m)
• Connections: (2) XLR+1/4” (6.35 mm) inputs; (2) XLR outputs; (1) IEC power cable input
• Input Level: Line +4 dBu (nominal)
• External Controls: Volume control, output mode switch, polarity-reverse switch, extended low-frequency switch, power switch
• Indicators: Signal/clip limiter LED, polarity-reverse LED, extended low-frequency LED, power switch LED
• Electronic Protections: Electronic clip, thermal and transducer overdrive protection
• Enclosure: Internally braced MDF cabinet; 36 mm mounting pole socket on top panel
• Rugged, mar-resistant splatter-spray finish always looks good, even with heavy use
• Power Connection: IEC with Mains Fuse
• AC Voltage Input: 100,110-120,220–240 V, 50/60 Hz
• Consumption: 1000 W Fuse: T10AL AC250V (100–120 V) or T5AL AC250V (220–240 V)
• Dimensions (H x W x D): 17.9” x 18.1” x 19.9” / 456mm x 459mm x 505mm
• Weight: 55.12 lbs. / 25 kg
• Design Origin: Designed and tuned in the USA
• Accessories: TS312S Cover
