Alto Professional TS312S
Photos
1/14

Alto Professional TS312S

Subwoofer amplifié de la marque Alto Professional appartenant à la série Truesonic 3

Écrire un avis ou Demander un avis
Avis
Comparateur de prix
Petites annonces

Annonces TS312S

Alerte nouvelle annonce

Forums Alto Professional TS312S

Images

Fiche technique

  • Fabricant : Alto Professional
  • Modèle : TS312S
  • Série : Truesonic 3
  • Catégorie : Subwoofers amplifiés
  • Poids du colis : 28.3 kg
  • Fiche créée le : 05/07/2019

Le TS312S est subwoofer amplifié 12" de 2000W.

Features

  • 2000 watts of peak power output
  • High-efficiency Class D amplifier
  • Transducer: 12-inch with 3-inch high-temperature voice coil
  • (2) XLR+1/4-inch combo inputs + (2) balanced XLR line outputs
  • XLR outputs, with six discreet output modes for ideal matching with companion speaker
  • Polarity Reverse switch and Extended LF switch for increased EQ control
  • Electronic clip, thermal and transducer overdrive protection
  • Rugged, internally-braced front-ported MDF cabinet with integrated 36mm pole socket
  • Rugged, mar-resistant splatter-spray finish always looks good, even with heavy use
  • Designed and tuned in the USA

Technical Data

  • Output Power: 2000 W peak, 1000 W continuous
  • Amplifier: High-efficiency Class D amplifier
  • Transducer: 12” (305 mm) woofer, 3” (76 mm) voice coil
  • Frequency Response: 44HZ – 95Hz (- 3 dB)
  • Frequency Range: 38Hz – 110Hz (-10 dB)
  • Maximum SPL: 129 dB (@ 1 m) 126 dB continuous (dB SPL @ 1 m)
  • Connections: (2) XLR+1/4” (6.35 mm) inputs; (2) XLR outputs; (1) IEC power cable input
  • Input Level: Line +4 dBu (nominal)
  • External Controls: Volume control, output mode switch, polarity-reverse switch, extended low-frequency switch, power switch
  • Indicators: Signal/clip limiter LED, polarity-reverse LED, extended low-frequency LED, power switch LED
  • Electronic Protections: Electronic clip, thermal and transducer overdrive protection
  • Enclosure: Internally braced MDF cabinet; 36 mm mounting pole socket on top panel
  • Rugged, mar-resistant splatter-spray finish always looks good, even with heavy use
  • Power Connection: IEC with Mains Fuse
  • AC Voltage Input: 100,110-120,220–240 V, 50/60 Hz
  • Consumption: 1000 W Fuse: T10AL AC250V (100–120 V) or T5AL AC250V (220–240 V)
  • Dimensions (H x W x D): 17.9” x 18.1” x 19.9” / 456mm x 459mm x 505mm
  • Weight: 55.12 lbs. / 25 kg
  • Design Origin: Designed and tuned in the USA
  • Accessories: TS312S Cover



Source : Site officiel

»
