Fender FSR 2012 American Hand-Stained Stratocaster

General

• Model Name: FSR American Special Hand-Stained Stratocaster®
• Model Number: 017-0171-342
• Series: American Special Series
• Color: Hand-Stained Satin Honey Burst (Satin Lacquer Finish)

Body & Neck

• Body: Alder
• Neck: Maple, Modern “C” Shape,
• (Satin Urethane Finish)
• Fingerboard: Maple, 9.5” Radius (241 mm)
• No. of Frets: 22 Jumbo Frets
• Scale Length: 25.5” (648 mm)
• Width @ Nut: 1.6875” (43 mm)

Hardware

• Hardware: Chrome
• Machine Heads: Fender® Standard Cast/Sealed Tuning Machines
• Bridge: Vintage Style Synchronized Tremolo
• Pickguard: 3-Ply Parchment/Black/Parchment

Electronics

• Pickups: 3 American Standard Strat® Single-Coil Pickups
• Pickup Switching: 5-Position Blade
• Position 1. Bridge Pickup
• Position 2. Bridge and Middle Pickup
• Position 3. Middle Pickup
• Position 4. Middle and Neck Pickup
• Position 5. Neck Pickup
• Controls:
• Master Volume,
• Tone 1. (Neck Pickup),
• Tone 2. Delta Tone (“Delta Tone” System Includes High Output Bridge Pickup and Special No-Load Tone Control for Middle and Bridge Pickups)

Miscellaneous

• Strings: Fender USA, Nickel Plated Steel, Gauges: (.009, .011, .016, .024w, .032, .042)
• Unique Features: Large ‘70s Style Headstock, Large ‘70s Style Decal, Parchment Pickup Covers and Plastic Parts,  Black Dot Position Inlays
• Source: U.S.
• Accessories: Deluxe Gig Bag, Polishing Cloth
• U.S. MSRP: $1,049.99
• INTRODUCED: 8/2012
• COMMENTS: Over 2500 made. Originally for GC, also sold in Europe. Originally advertised as American Special Stratocaster® by GC. Name changed to American Hand-Stained Stratocaster® 5/2013
• WRENCH SIZES: Truss Rod Adjustment Wrench, (1/8” Hex), P/N 0023811000,
• Saddle Height Adjustment Wrench, (1.5 mm Hex), P/N 0050919000
