- Fabricant : Technics
- Modèle : SU-V9
- Catégorie : Amplificateurs Hi-Fi
- Fiche créée le : 12/01/2009
| Type | Integrated DC amplifier |
| Effective output (20 Hz to 20 kHz) | 120W + 120W (4 Ω, 0.007%) 120W + 120W (8 Ω, 0.003%) |
| Total harmonic distortion factor | 0.003% (Rated Output -3dB, 20 hz to 20 khz) |
| Power Bandwidth (THD 0.02%) | 5 Hz to 100 kHz |
| TIM | Unmeasurable |
| Residual Noise (straight DC) | 0.7mV |
| Damping factor (8 Ω) | 80 |
| Load impedance | Main or remote : 4 Ω ~ 16 Ω Main and remote : 8 Ω ~ 16 Ω |
| Input Sensitivity / Impedance | Phono MM : 1.0 mV, 2.5mV/47k Ω Phono MC : 100 μ V/100 Ω, 250 μ V/220 Ω Tuner, Aux, Tape : 150mV/33k Ω |
| Phono maximum allowable input (1 kHz, RMS, THD 0.01%) |
MM:170mV(2.5mV) MC : 17 mv (250 μ V) |
| Total harmonic distortion factor | Phono MM → Rec out : 0.0005% (1 kHz, output 5 V) |
| Frequency characteristic | Tuner, Aux, Tape : 20 Hz to 20 kHz + 0 -0.2 dB 0.5 Hz ~ 170 kHz + 0 -3dB |
| Signal-to-noise ratio | Phono MM : 88 dB (2.5 mV input) Phono MC : 71 dB (250 μ V input) Tuner, AuX, Tape : 103 dB |
| Tone control | Super Bass : -0dB to + 10 dB (30 Hz) Bass : ± 7 dB (100 Hz) Treble : ± 10 dB (20 kHz) |
| Turnover frequency | Super Bass : 75 Hz, 150 Hz (12dB/oct.) Bass:500Hz Treble:2kHz |
| Filter | High : 7 kHz, -6dB/oct. Subsonic : 20 Hz, -12dB/oct. |
| Loudness control | 7 dB (50 Hz, Volume-30dB) |
| Output voltage of preamplifier section (Rec out) | 150mV |
| Pwer | 100 VAC, 50Hz/60Hz |
| Power consumption | 205W |
| External dimensions | Width 430x Height 120x Depth 350 mm |
| Weight | 14.7kg |
