SD9, Console numérique de la marque DiGiCo.


1 avis d'utilisateur
Occasion à partir de 10 000 € argus occasion : 10 628 €Attention, cote argus calculée sur un petit nombre d'annoncesAvertissement important

Fiche technique DiGiCo SD9

  • Fabricant : DiGiCo
  • Modèle : SD9
  • Catégorie : Consoles numériques
  • Fiche créée le : 10/07/2011

General

  • Faders 24 x 100mm touch-sensitive, motorised
  • Screens 1 x 15” (38cm) LCD high - resolution touch screen
  • Meters 24 x 8-segment LED bargraph
  • Input Channels 40 Mono or Stereo channels
  • Busses 16 Mono or Stereo busses + LR or LCR master
  • Solo busses 2 mono or stereo busses
  • Matrix 8 x 8 matrix (additional to busses above)
  • Control Groups 8, selectable for VCA-style, Moving fader, Mute Group
  • Graphic Eq 16 x 32-band, Gain +/- 12dB
  • Internal FX 4 Stereo FX processors
  • Local I/O 8 x mic/line I/O, 4 x AES/EBU I/O (mono)
  • MADI interface 1 75 ohm BNC connectivity
  • D-Rack interface 2 RJ45 shielded connectivity
  • MIDI interface In / Out / Through
  • VGA port DB-15 mini-female (1024 x 768 resolution)
  • USB ports (3) USB2
  • Ethernet port RJ45
  • Light connection (2) XLR3 1.2 – 12V
  • Ext Sync Word clock, AES, MADI
  • Headphone TRS unbalanced / 8-600 ohms 1/4 inch Jack
  • GPI 2. 1/4 inch Jack
  • GPO 2. 1/4 inch Jack

D-Rack

  • 32 mic/line inputs on 3 pin female XLR
  • 8 line outputs on 3 pin male XLR
  • Optional 8 line outputs on 3 pin male XLR or 4 stereo AES outputs on 3 pin male XLR
  • Interface to SD9 RJ45 shielded  connectivity
  • Optional 19” rack ears
  • Mains Operating range
  • SD9 surface   90-264V 47-63Hz auto ranging
  • D-Rack    90-264V 47-63Hz auto ranging
  • Mains Power Consumption
  • SD9 surface   208W 232VA (with twin PSU’s)
  • D-Rack    68W 108VA (with twin PSU’s)
  • Operating temperature   1 degree C to 40 degrees C Range
  • Storage temperature  -10 degrees to 60 degree C Range
  • Relative humidity range 0%-90% non-condensing

Physical

  • Weights and Dims  SD9: 36KGS. 878W 785D 262H
  • Weights and Dims  D-RACK: 7.4KGS. 412W 312D 179H

Audio Specifications

These specifications relate to both the D-Rack and SD9 local I/O

  • Analogue inputs:
    Gain     10 to 60dB
    Pad     -20dB
    Crosstalk    Less than 90dB 100Hz to 10kHz
    Input impedance   2500 ohms (no pad) 2650 ohms (with pad)
    Equivalent input noise  Typically -127dB (150 ohm source)
    Maximum input level  +9dB no pad +28dB with pad
    Analogue outputs:
    Output noise   typically less than -91dB
    Maximum level   +22dB
    Output impedance  Less than 50 ohms
  • Analogue I/O:
    Distortion (30dB gain)  100Hz typically 0.005%
    +10dB output   1kHz   typically 0.009% 10kHz typically 0.05%
    Frequency response  10Hz-20kHz +0/-1dB
  • Digital Inputs:
    Standard    AES/EBU Sample rate converters  SwitchableInput impedance   110 ohms
  • Digital outputs:
    Standard    AES/EBUSample rate converters  non (console word clock only)Output impedance  110 ohms
  • Digital I/O:
    Frequency response  10Hz-20kHz +/-0.1dB
    Distortion -1dBFS  100Hz typically 0.0002%
    1kHz   typically 0.0015%
    10kHz  typically 0.0015%
  • General:
    Clocking
    Clock sources   Internal, MADI, Word clock
    Clock output   BNC TTL level
    Clock accuracy   +/-25ppm
    Jitter     <+/- 5nS 50Hz-100kHz

Processing Channel Specifications

  • Input Channel
  • Name User-defined / Presets
  • Channel Selection Mono / Stereo
  • Input Routing Main & Alternate Input
  • Analogue Gain -20 to +60dB
  • Phase Normal / Reverse
  • Digital Trim -40 to +40dB
  • Delay <1.3 sec (coarse & fine control)
  • LPF 20 – 20kHz, 24dB / Oct
  • HPF 20 – 20kHz, 24dB / Oct
  • Insert A (pre eq/dyn) On/Off
  • Insert B (post eq/dyn) On/Off
  • Equalisation 4 band PEQ (or Dynamic up to 8 Stereo Processing Paths with Overdrive Software)
    (hi & lo bands switchable shelving or bell)
    Freq; 20 – 20kHz
    Gain; +/- 18dB
    Q: 0.1 -20 (parametric) / 0.10-0.85 (shelf)
  • Dynamic Eq on/off
    Over/under
    Band on/off
    Threshold; -60 – 0dB
    Attack; 500us – 100ms
    Release; 10ms – 10s
    Ratio; 1:1 – 50:1
  • Compressor Single (or Multiband, up to 8 Stereo Processing Paths with Overdrive Software)
    on/off
    Threshold; -60 – 0dB
    Attack; 500us – 100ms
    Release; 10ms – 10s
    Ratio; 1:1 – 50: 1
    Gain; 0 to +40dB with Autogain option
    Link; any channel / buss
    Hi crossover; 20Hz – 20kHz
    Lo crossover; 20Hz – 20kHz
  • Gate on/off
    Threshold; -60 – 0dB
    Attack; 50us – 100ms
    Hold; 2ms – 2s
    Release; 5ms – 5s
    Range; 0 - 90dB
    Key; Any source
    Key listen
    Freq/width; 20 – 20kHz
  • EQ/Dyn order EQ/Dyn or Dyn/EQ
  • Mute Channel mute / hard mute
  • Solo Solo Buss 1 / Solo Buss 2 / Both,
    Auto solo
  • Channel Safe Input, eq, dyn, aux, pan, fade/mute, inserts, buss, directs, full safe
  • Output Routing Buss, Insert A, Insert B, FX
    Direct: on/off, pre-mute / pre-fade / post-fade, level +/- 18dB
  • Fader 100mm motorised fader -∞ to +10dB

Processing Channel Specifications

  • Aux / Group / Matrix Output
  • Name User-defined / Presets
  • Phase Normal / Reverse
  • Digital Trim -20 to +60dB
  • Delay <1.3 sec (coarse & fine control)
  • LPF 20 – 20kHz, 24dB / Oct
  • HPF 20 – 20kHz, 24dB / Oct
  • Insert A (pre eq/dyn) On/Off
  • Insert B (post eq/dyn) On/Off
  • Equalisation 4 band PEQ (or Dynamic up to 8 Stereo Processing Paths with Overdrive Software)
    (hi & lo bands switchable shelving or bell)
    Freq; 20 – 20kHz
    Gain; +/- 18dB
    Q: 0.1 -20 (parametric) / 0.10-0.85 (shelf)
  • Dynamic Eq on/off
    Over/under
    Band on/off
    Threshold; -60 – 0dB
    Attack; 500us – 100ms
    Release; 10ms – 10s
    Ratio; 1:1 – 50:1
  • Compressor Single (or Multiband, up to 8 Stereo Processing Paths with Overdrive Software)
    on/off
    Threshold; -60 – 0dB
    Attack; 500us – 100ms
    Release; 10ms – 10s
    Ratio; 1:1 – 50: 1
    Gain; 0 to +40dB with Autogain option
    Link; any channel / buss
    Hi crossover; 20Hz – 20kHz
    Lo crossover; 20Hz – 20kHz/li>
  • Gate on/off
    Threshold; -60 – 0dB
    Attack; 50us – 100ms
    Hold; 2ms – 2s
    Release; 5ms – 5s
    Range; 0 - 90dB
    Key; Any source
    Key listen
    Freq/width; 20 – 20kHz
  • EQ/Dyn order EQ/Dyn or Dyn/EQ
  • Mute Channel mute / hard mute
  • Solo Solo Buss 1 / Solo Buss 2 / Both, Auto solo
  • Channel Safe trim, eq, dyn, fade/mute, inserts, outputs, full safe
  • Output Routing Outputs, Insert A, Insert B, FX
  • Fader 100mm motorised fader -∞ to + 10dB

Distribué par apexaudio

»

Acheter d'occasion DiGiCo SD9

DiGiCo SD9 Sd 9 core 2 10 000 € »
DiGiCo SD9 DIGICO SD9 Core 2 10 889 € »

Avis utilisateurs DiGiCo SD9

Fcala05/09/2012

L'avis de Fcala"Très bien "

DiGiCo SD9
Intuitive, efficace, elle sonne. D-rack 32/16 inclu avec 75m CAT5
Le flight est lourd mais protège bien la console

UTILISATION

Grand écran tactile, les fonctions de base sont simples à utiliser, mais la partie snapshot est plus complexe que sur les Yamaha
Version supercharged 48 voies, digitube ...

SONORITÉS

Effets de qualité relative , Eq efficaces,

AVIS GLOBAL

Utilisée depuis un an, rien à reprocher, c'est un bon investissement ! À voir au fil des années et avec les différentes mise à jour
»
