Elka OMB3

The OMB 3 from Elka aka One Man Band is an FM and PCM Rom based synthesizer arranger instrument. There is an FM synthesizers on board along with a PCM/Wavetable synthesizer for drums.

The FM synthesizer section offers 24 presets of synth sounds. No editing capabilities are available however the user can stack/layer two sounds with each other making for interesting and heavier sounding arrangements.
The Sequencer Section can hold up to 9 parts making it 9 part multitimbral. There is also an Auto Bass Accompaniment within the Sequencer Arranger with song functions available like tempo, variation, and rhythm.

Synthesis: Frequency Modulation, ROM, Wave Table Oscillators

Oscillators: 3

Waveforms: ROM, Sine, Wave Table

Osc Modulation: Envelope, Fader, LFO, Sequencer

LFO: 1

LFO Parameters: Sine

LFO Notes::LFO is preset for vibrato with fixed rate and depth.Polyphony & Tuning

Polyphony: 9

Timbrality: 4

Tuning: Standard Patches

Patches RAM: 24

Patches ROM: 24

Storage: Internal

Editing: CV, MIDI Sequencer Sequencer song arranger with rhythms, variation, tempo set, and, autobass chords Case

Case Details: Desktop Module

Controls: Buttons, Faders

Display Type: Numeric

Display Count H: 4 Display Count V: 1 Connections

Audio Output Connections: 1/4" Phone Jack, Stereo Main

Audio Output Count: 2

MIDI Ports: IN

CV Ports: CV IN Production

Year Released: 1988
