Annonces DSP4000B+
Alerte nouvelle annonceForums Eventide DSP4000B+
Images
Fiche technique
- Fabricant : Eventide
- Modèle : DSP4000B+
- Catégorie : Processeurs multi-effets
- Fiche créée le : 23/03/2011
Sample Rates: 96, 88.2, 48, 44.1, KHz External
Digital Inputs/Outputs: - 2 AES/EBU or SPDIF at 44.1 to 96KHz Analog Inputs 24 bit conversion. Any combination of 2 XLR (20kohms bridging) or 2 mono jacks (150kohms)
Impedance: >20kOhm, Bridging
Full Scale Input Level: 26dBu
Dynamic Range: >105dB
Signal to Noise Ratio: >105dB A-weighted
THD+N: <.0025%@ 1kHz, -3dBFS
Crosstalk: <-100dB @ 20Hz to 20 kHz, -3dBFS
Analog Outputs: XLR balanced
Impedance: <50ohm
Full Scale Output Level: 26dBu
MIDI Connections: 5 pin DIN Output and Thru 7 pin DIN Input with Output capability
Memory Card Interface: 68 pin PCMCIA 2.0/JEIDA 4.0
Supports type 1 SRAM cards up to 4MB for data storage
Factory Preset Capabilities (at 48K sampling) Pitch Shifting: up to 11 voices
Compressor/Limiter: up to 4 instances
Equalization: up to 128 bands parametric single input, 64 bands at 2 channels
Sampling with time compression/expansion (48K): Up to 174 seconds mono (DSP 7500 only)
Frequency Response:
+0/-0.1dB @
sample rate:
44.1KHz: 20Hz-20kHz,
48kHz: 20Hz-22kHz
88.2kHz: 20Hz-41kHz
96kHz: 20Hz-44kHz
Frequency Response:
+0/-3.0dB @
sample rate:
44.1KHz: 5Hz-21kHz
48kHz: 5Hz-23kHz
88.2kHz: 5Hz-42kHz
96kHz: 5Hz-46kHz
Distribué par Mogar
»
