Fiche technique
- Fabricant : Cyberstep
- Modèle : KDJ-One
- Catégorie : Pocket PC / PDA
- Autres dénominations : kdj one, kdjone, kdj 1
SYNTHESIZER
| Max. Polyphony | 64 voices |
|---|---|
| Waveform Memory | 14 MB (Extendable) |
| Waveform | 240 Types (Multi-Layered) |
| Oscillator | 2 Units 10 algorithms |
| Filter | 7 Types |
| Modulator | 4 Units, 10 Algorithms (Including Step Modulator) |
| Num. of Programs | Preset: 200 Synth Patches, 100 Drum Kits, 100 Audio Clips |
| Max. Audio Volume | 1 GB Per Project |
| Effects | 20 Types, 2 Systems for Each Track, and Master Effect |
SEQUENCER
| Tracks / Pattern | 6 |
|---|---|
| Resolution | 384 tick / Quarter Note |
| Tempo | 40 - 400 |
| Recording Mode | Loop (Real Time) Recording, Step Recording, Automation Recording |
| Score Editing Mode | Piano Roll |
| Pattern Length | 999 Bars |
| Song Length | 9,999 Bars |
| Number of Patterns | 999 Per Project |
| Number of Songs | 99 Per Project |
APPEARANCE
| Keypad | 16 keys with velocity, Octave Up/Down, Volume Up/Down, and Tap Tempo Button |
|---|---|
| Controller | D Pad, Button x 4, Jog Dial x 1, Analog Stick for Pitch Bend and Modulation |
| Case Size | 174.2 mm x 115.5mm x 29.5mm |
| Weight | 480 g |
HARDWARE SPECIFICATIONS
| CPU | ARM Cortex-A8 1GHz |
|---|---|
| Display | 5.0 inch WVGA ( 800 x 480 ) with Multi-Touch Panel |
| Main Memory | 512 MBytes |
| SSD | 4.0 GBytes |
| External Storage | USB Memory |
| Battery | Lithium Ion Battery 7.4V 3,000mAh |
| Connection | USB 2.0 host x 1, mirco USB x 1 |
| Audio I/O | Phone, Mic/Line in, Line out, Built-in MIC |
| Speaker | 2.0 W (1.0 W + 1.0 W Stereo) 250 Hz - 20,000 Hz |
»
