Fiche technique
- Fabricant : Scott Sommerfeldt
- Modèle : a 416
- Catégorie : Amplificateurs Hi-Fi
- Autres dénominations : a416
Outup power : 20Watts, minimum continuous RMS power output per channel both channel driven into 8 ohms fron 20 to 20,000 Hz with no more than 0,5% total harmonic distortion.
Maximum total harmonic distorsion : 0.5%
Maximum intermododulation distorsion from 0.5Watt to rated output : 0.3%
Input Sensibility
Phono : 2.5mV
Mic : 6mV
Aux : 150mV
Tuner : 150mV
Tape : 150mV
Signal to noise ratio, weighted (input shorted)
Mic : 75dB
Phono : 70dB
Aux : 80dB
Tuner : 80dB
Tape : 80dB
Frequency response at 1watt + ou - 1dB
Phono 20 to 20,000 Hz
Aux : 16 to 32,000 Hz
Phono overload (maximum input signal before clipping) : 100mV
Mic overload : 220mV
Input Impedance
Phono : 47,000 ohms
Mic : 47,000 ohms
Aux : 60,000 ohms
Tuner : 60,000 ohms
Tape : 60,000 ohms
Separation
Photo : 42dB
Aux : 46dB
Speaker load impedance : 8 to 600 ohms
Headphone output impedance 8 to 600 ohms
Damping factor : 35
Controls
Bass control range : +/- 10dB at 100Hz
Treble control range : +/- 10dB at 10,000Hz
Loudness compensation : 3dB at 10,000Hz and 7dB at 100Hz
Power Line requirements
Line voltage and frequency : 220VAC; 60Hz
Power comsumption - full load : 190watts
Power consuption - idle : 8 watts
Dimensions
Height : 12,5cm
Width : 35,0cm
Depth : 28,5cm
Net weigth : 7,2kg
Shipping weigth : 8,2kg
