Sennheiser SK 6000

• Fabricant : Sennheiser
• Modèle : SK 6000
• Série : Digital 6000
• Catégorie : Emetteurs & récepteurs
• Fiche créée le : 07/03/2017

Récepteur ceinture pour le système HF Digital 6000, pour micros lavalier et instruments

The lightweight SK 6000 digital pocket transmitter can be combined with lavalier microphones and headsets, and shines as a high-end solution for instruments like guitar and bass. Maximum transmission reliability of the renowned Long Range mode and outstanding audio quality of the Sennheiser Audio Codec (SeDAC) are shared with the wireless masterpiece, Digital 9000. Sophisticated electronics prevent disturbing intermodulation, even with numerous transmitters in the most confined spaces. This allows operation in an equidistant frequency grid and efficiently utilizes the available frequency spectrum.

The right microphone for every application: Sennheiser lavalier microphones MKE 1, MKE 2 and MKE 40, Headsets HSP 2, HSP 4 and SL Headmic.

A special magnesium housing offers the perfect balance between light weight, inconspicuous size and rugged construction with shielding against moisture. The BA 61 lithium-ion battery pack ensures up to 6.5 hours of operation. Alternatively, operation is also possible with batteries from the B 60 battery set.

Additionally, the transmitter is compatible with the EK 6042 and EM 9046 in Long Range mode.

• Three frequency variations (470-558 MHz, 550-638 MHz, 630-718 MHz)

• Sennheiser 3-pin connector allows connection to a variety of microphones or an instrument

• Highly effective intermodulation protection

• AES 256 encryption and Digital 9000 encryption

• Compatible with EK 6042 and EM 9046 in Long Range mode

• Li-ion battery packs with 5.5 hours run time

• Magnesium housing

• Dimensions

  76 x 62 x 20 mm (with BA 61 battery pack)

• Poids

  Approx. 147 g (with BA 61 battery pack and belt clip)

• Entrée audio

  3-pin audio socket

• • Alimentation

    Max. 960 mW

  • Puissance de sortie HF

    25 mW rms, 50 mW peak

  • Bande passante commutable

    88 MHz

  • Autonomie

    6.5 h (with BA 61 battery pack)

  • Modulation

    Digital modulation long range mode

  • Gain

    Mic: adjustable in 3 dB steps from 0 dB to +42 dB
    Line: adjustable in 3 dB steps from -6 dB to +9 dB

  • Plage de fréquences

    470 to 718 MHz, subdivided into 3 ranges:
    SK 6000 A1 - A4: 470 - 558 MHz
    SK 6000 A5 - A8: 550 - 638 MHz
    SK 6000 B1 - B4: 630 - 718 MHz

  • Impédance d'entrée

    Mic: 22kΩ
    Line: 1 MΩ

  • Codec audio

    SeDAC (Sennheiser Digital Audio Codec)

  • Réponse en fréquence BF

    Line: 30 Hz - 20 kHz (3 dB)
    Mic: 60 Hz - 20 kHz (3 dB)

  • Frequency stability

    < 5 ppm

  • Tunability

    25 kHz steps

  • Lower cut-off-frequency

    Mic: adjustable, 60 Hz, 80 Hz, 100 Hz, 120 Hz
    Line: 30 Hz

  • Instrument cable emulation

    Adjustable cable length with 3 steps

  • Encryption

    AES 256 and Digital 9000 encryption
