- Fabricant : Soundcraft
- Modèle : Vi7000
- Série : Vi
- Catégorie : Consoles numériques
- Fiche créée le : 17/04/2015
128 inputs and 32 mono/stereo busses digital mixing consoles
- The latest Vistonics™ & FaderGlow™ interface
- Up to 128 inputs and 32 mono/stereo busses
- Enhanced audio processing with 96kHz sample rate option
- Powerful new features including BSS DPR901ii™ Dynamic EQ
- New Local Rack hardware for 384 I/O channels
- 128 channel record interface via MADI or Dante™
- Mix live with UA™ plug-ins (via Realtime Rack)
- Huge connectivity options - Dante™, Rocknet™, Ethersound™, Cobranet™, MADI and more
| Frequency Response | |
| Stagebox Mic input to Line output | +0/-1dB, 20Hz-20kHz |
| AES/EBU In to AES/EBU Out. | +0/-0.2dB, 20Hz-20kHz |
| T.H.D. & NOISE | |
| Stagebox Mic In (min gain) to Local Line Out, 22Hz-22kHz | <0.003% @ 1kHz |
| Stagebox Mic In (max gain) to Local Line Out, 22Hz-22kHz | <0.020% @ 1kHz |
| Local Line In to Line Out, 22Hz-22kHz | <0.003% @ 1kHz |
| Mic Input E.I.N (22Hz-22kHz bandwidth, unweighted | <-126dBu (150Ω source) |
| Residual Noise, Stagebox line output; no inputs routed, Mix fader @0dB | -91dBu |
| CMRR, Stagebox Mic input. | 80dB @ 1kHz |
| Sampling Frequency | 48kHz or 96kHz |
| Latency, Stagebox Mic Input to Local Line output | <2ms @48kHz |
| AES/EBU Input Sample Rate | 32–108kHz (with SRC enabled) |
| DSP resolution | 40-bit floating point |
| Internal clock accuracy | <+/-50ppm |
| Internal clock jitter | <+/-5ns |
| External Sync | BNC Wordclock |
| Input & Output Levels | |
| Mic Inputs | +28dBu max |
| Line Inputs | +22dBu max |
| Line Outputs | +22dBu max |
| Nominal Operating Level | +4dBu (-18dBFS) |
| Input & Output Impedances | |
| Mic Inputs | 10kΩ |
| All other analogue Inputs | >10kΩ |
| Line Outputs | <75Ω |
| AES/EBU Outputs | 110Ω |
| Oscillator | 20Hz to 20kHz/Pink/White Noise, variable level |
| Stagebox HP Filter | 80Hz fixed, 12dB per octave |
| Channel HP filter | 20Hz-600Hz, 18dB per octave |
| Channel LP filter | 1kHz-20kHz, 18dB per octave |
| EQ (Inputs and bus Outputs) | HF: 20Hz-20kHz, +/-18dB, Q= 0.3-8.7 or shelving Hi-Mid: 20Hz-20kHz, +/-18dB, Q=0.3-8.7 Lo-Mid: 20Hz-20kHz, +/-18dB, Q=0.3-8.7 LF: 20Hz-20kHz, +/-18dB, Q= 0.3-8.7 or shelving |
| Metering | Internal 20-segment LED bargraphs plus 9-segment gain reduction meters for all inputs and Outputs. Peak hold variable from 0-2s. |
| Mains Voltage operating range | 90-264V, 47-63Hz, autoranging |
| Mains Power Consumption | 300W |
| Operating Temperature Range | 0°C – 45°C (32°F – 113°F) |
| Relative Humidity | 0% – 90%, non-condensing Ta=40°C (104°F) |
| Storage Temperature Range | -20°C – 60°C (-4°F – 140°F) |
