Acheter neuf MOTU 8PRE-ES
- Amazon.fr En stock / Livré en 24h 1 810,00 €
- Energyson Pas de stock / Livré en 72h 1 366,00 €
- Global Audio Store Pas de stock / Livré en 10 jours 1 490,00 €
- Terre de Son Pas de stock / Livré en 5 jours 1 499,00 €
- SonoVente Pas de stock / NC 1 499,00 €
Annonces 8PRE-ES
Me prévenir à chaque nouvelle annonce sur ce produitNews
Images
Fiche technique
- Fabricant : MOTU
- Modèle : 8PRE-ES
- Catégorie : Interfaces audio Ethernet
- Fiche créée le : 27/06/2018
Interface audio numérique Thunderbolt, USB et réseau équipée de 8 préamplis micro
| Sample rates | 44.1, 48, 88.2, 96, 176.4, 192 kHz |
| Mic/line/instr inputs | 8 x XLR/TRS "combo style" mic/line/instr inputs Preamp gain: 0 to +63 dB (digitally controlled) TRS max level with pad: +17 dBu |
| Analog outputs | 8 x 1/4" TRS line out (balanced, DC coupled) Max level: +20 dBu (digitally adjustable -4 to +20) 2 x 1/4" TRS stereo headphone |
| Digital I/O | 2 banks (16 ch) of ADAT optical at 1x sample rates 2 banks (8 ch) of SMUX optical at 2x sample rates Switchable to stereo TOSLink (optical S/PDIF) |
| Total I/O | 24 in / 28 out (52 total) at 1x sample rates 16 in / 20 out (36 total) at 2x sample rates 8 in / 12 out (20 total) at 4x sample rates |
| Computer I/O | 1 x Thunderbolt 1 (Mac and Win) Thunderbolt 2 & 3 compatible 1 x USB 2.0 audio class compliant USB 3.0 and iOS compatible |
| Computer I/O channels Thunderbolt |
128 in/out at 1x (44.1 to 48 kHz) 128 in/out at 2x (88.2 to 96 kHz) 64 in/out at 4x (176.4 to 192 kHz) |
| Computer I/O channels USB |
64 in/out at 1x (44.1 to 48 kHz) 32 in/out at 2x (88.2 to 96 kHz) 24 in/out at 4x (176.4 to 192 kHz) |
| Sync I/O | 1 x BNC word clock in/out |
| Network I/O | 1 x RJ45 AVB/TSN Ethernet (1 Gbps) |
| Headphone | 2 x 1/4" TRS stereo phone (assignable) |
| Phantom power | 8 x individual +48V |
| Front panel | 2 x 1/4" TRS headphone output 2 x digital rotary encoders • phone vol 4 x digital rotary encoders • mic/instr input gain 2 x large digital rotary encoders • main vol / menu 8 x small switches • (4) Pad / (4) 48V Phantom pwr 10 x large switches • menu nav / A-B select, etc. 2 x LCD (128 x 160) for level meters / menu nav |
| Power | International 100-240V autoswitching supply 50-60 Hz • 0.5A max |
| Dimensions and weight |
(width x depth x height, enclosure only, with rack brackets) 19 x 7 x 1.75 inches 48.3 x 17.75 x 4.5 cm 4.2 lbs / 1.9 kg |
Distribué par MSC Distribution
»
