Analogue outputs: 4 balanced stereo pairs using 32 bit DAC at 96kHz sample rate.
USB audio: USB Audio Class 2.0 - 8 stereo 24-bit streams at 96kHz with 48kHz downsample mode available.
USB 2.0 and legacy (5-pin DIN connector) MIDI
Display: High resolution 256x64 pixel graphic OLED
Polyphony: Guaranteed contention-free 128 voice channels. A Dual Mode or Dual Filter Patch uses two voice channels per note played. Up to 32 notes (single or dual) per multitimbral part.
Multitimbrality: 8 independent Parts each with dedicated 9 module multi effects with dedicated audio stream via USB. Each Part can be mixed to one of the four analogue stereo line outputs.
Full keyboard microtuning capability with MIDI Tuning Standard (MTS) support.
Oscillators: Two primary virtually alias-free Oscillator Groups per voice each with sawtooth, pulse, wavetable and noise available simultaneously. Each oscillator group also has an independent detunable suboscillator with four selectable shapes and two selectable pitches. Real Hard Sync, Ring Modulation and FM (frequency modulation) is available between the oscillator groups.
Hypersaw: 6 or 12 real oscillator hypersaw with adjustable geometric detuning and intensity algorithm.
Wavetables: 4096 18-bit linear PCM single-cycle oversampled wavetables covering a huge range of synthetic and emulated sound sources. Two independent wavetables per voice.
Filters: Accurate emulations of classic analogue ladder filters with low pass, band pass and high pass configurations. 2-pole (12dB/octave) and 4-pole (24dB/octave) responses are available for all three filter types. A Patch can be configured to have linked or independent parallel filters.
Envelope Generators: Three fast-response ADSR envelope generators.
LFOs: 3 LFOs with 64 wavetable shapes. Monophonic, polyphonic, random, antiphase and quadrature phase settings.
Modulation Matrix: 6 channels with up to 3 destinations per channel.
Effects: Nine module stereo effects unit per Part with a 3-band shelving EQ, a Formant Filter, 5-mode Distortion module, dual Limiters, stereo Delay module, 6-stage Phaser, Chorus/Flanger module and a Reverb module. All 72 effects modules can be used simultaneously without affecting polyphony.
Arpeggiator with 128 preset patterns, chord mode, MIDI clock.
Patch storage: 3,328 in total all of which are user programmable.
