Fiche technique
- Fabricant : Yorkville
- Modèle : Unity U215
- Catégorie : Enceintes de sono passives
- Fiche créée le : 05/03/2016
| System Type | Three-Way |
| Active or Passive | Passive |
| Program Power (Watts) | 1800 Watts (3600 Watt Peak) |
| Biampable | Yes |
| Nominal Impedance (Ohms) | 4 |
| Sensitivity (dB @1Watt/1m) | 98 |
| Max SPL (dB) | 134dB Peak (130 Continuous) |
| Frequency Response (Hz +/- 3dB) | 45 - 20k |
| Crossover Frequency (Hz) | 300 / 1250 |
| Driver Configuration | 2x15-inch / 3x5-inch / 1.75-inch |
| HF Driver(s) | 1.75 inch polyester |
| HF Impedance (Ohms) | 8 |
| HF Horn | Conical Unity™ horn (1 inch throat) |
| HF Dispersion (°H x °V) | 60 x 60 |
| HF Protection | PTC™ |
| MF Driver(s) | 3 x 5 inch ceramic 1 inch voicecoil |
| MF Horn | Conical Unity™ horn |
| MF Dispersion (°H x °V) | 60 x 60 |
| LF Driver(s) | 2x15-inch w/ 3-inch voicecoil |
| LF Impedance (Ohms) | 4 |
| Inputs - 1/4" Jacks | 2 |
| Inputs - Speakon 4-pin | 2 |
| Bar Handles | 2 Side |
| Flying Hardware | 3/8inch x 9 (all corners 1 pullback) |
| Enclosure Materials | 15mm 11-ply Birch |
| Grille | Perforated Metal |
| Covering / Finish | Black Ozite (Carpet) |
| Optional Covering / Finishes | Black Ultrathane Paint (U215B) |
| Dimensions (DWH xbackW, inches) | 16.25 x 19.25 x 50 x 9.5 |
| Dimensions (DWH xbackW, cm) | 42 x 49 x 127 x 24 |
| Weight (lbs/kg) | 113.8 / 51.6 |
