- Fabricant : Electro-Voice
- Modèle : XLE181
- Catégorie : Enceintes d'array
- Fiche créée le : 02/09/2011
Technical specifications
Frequency Response (-3dB): 90 Hz-18 kHz1
Frequency Range (-10 dB): 75 Hz-20 kHz1
Max Calculated SPL: 137 dB Cont., 143 dB Peak2
Horizontal Coverage: 120°
Vertical Coverage: Array Dependant, Software
Definable
Rigging: Fully Captive Aluminum, 1°
increments, 16 elements with 8 to 1
Safety Factor
LF Power Handling: 200W Cont., 800W Peak
HF Power Handling: 80W Cont., 320W Peak
LF to HF Crossover Frequency: 1760 Hz3
LF Passband: 1 x 8 inch DVN2080, 16 ohms
HF Passband: 2 x ND2S-8, 16 ohms
Connectors: 2 x NL8
Enclosure: 13-ply birch plywood with EVCoat
Grille: Galvannealed steel with powder
coat paint
Environmental Specifications: IEC 529 IP24, MIL 810
Dimensions (H x W x D): 9.90 in x 20.30 in x 14.52 in (251
mm x 516 mm x 369 mm)
Net Weight: 38 lb (17.2 kg)
Shipping Weight: 41 lb (18.4 kg)
