Fiche technique
Horizontal Coverage:
Angle Degrees (-6 dB): 70 (+20, 15)
Average Range: 500 Hz 16 kHz
Vertical Coverage: Angle Degrees (-6 dB): 40 (+ 11, 11)
Average Range: 2 kHz 16 kHz
Directivity Factor (Q): 19.0 (+6. 7)
Throw: Medium Directivity Index (Di): 12.8 dB (+2.0, -2.0)
Average Range: 1 kHz 16 kHz
Usable Low-Frequency Limit: 400 Hz
Minimum Recommended Crossover Frequency: 500 Hz
Axial Pressure Sensitivity¹ : 114 dB SPL. 1 W @ 1 m
Construction: Molded structural foam (nominal 10 mm [0.38 in] wall thickness)
Overall Dimensions:
Mouth Height: 279 mm [11 in]
Mouth Width: 445 mm [17.5 in]
Length. 236 mm [9.28 in]
Mounting Dimensions.
Rear Height: 235 mm [9.25 in]
Rear Width: 400 mm [15.75 in]
Baffle Cutout Required: [Front mounting only] Height: 238 mm [93/8 in] Width: 403 mm [157/8 in]
Net Weight: 2.2 kg [6 lb] Shipping Weight. 4.6 kg [10 lb]
Measured on axis in the far field with I watt input (4 0 volts RMS. 16 ohms) and referenced to I meter distance using the inverse square law Listed sound pressures (SPL re 20 µPa) represent an average from 1 kHz to 4 kHz using the 2446, 2450 or 2485 driver
