Annonces SA 115S (Series Synergy)
Alerte nouvelle annonceImages
Vidéos
Fiche technique
- Fabricant : Yorkville
- Modèle : SA 115S (Series Synergy)
- Catégorie : Subwoofers amplifiés
- Fiche créée le : 12/01/2021
Specifications
|
System Type |
Active Subwoofer |
|
Active or Passive |
Active |
|
Program Power (Watts) |
4500 Watts Program (9000 Watts Peak) |
|
Measured Max SPL (C-Weighted, Max Hold) |
129dB Cont. 135 dB Peak |
|
Frequency Response (Hz +/- 3dB) |
31Hz-100Hz |
|
Crossover Frequency (Hz) |
100 Hz lowpass |
|
Cabinet Configuration |
Tapped Horn |
|
Driver Configuration |
1x15" LF woofer |
|
LF Driver(s) |
15" Neodymium with 4.5" Voice Coil |
|
LF Program Power(Watts) |
4500 Watts Program (9000 Watts Peak) |
|
LF Impedance (Ohms) |
4 ohm Load |
|
LF Protection |
Excursion, Voice Coil Thermal (RMS) |
|
LF Amplifier Type |
Class D |
|
Cooling Scheme |
Convection |
|
Power Cable |
Removable Locking Powercon True Input and Loop Thru Output |
|
Power Switch |
Yes |
|
Inputs |
1 XLR with 2x XLR Parallel out, Impedance 35k ohms |
|
Input Sensitivity (Vrms Sine) |
Line in 1.4 at center, 0.56 at max |
|
Level Controls |
Volume, -∞,0dB,8dB (Min, Top, Max) |
|
EQ Controls |
Thermal Limiter Advance for power consumption management |
|
Limiter |
Excursion, Thermal (RMS), Clipping |
|
LED Indicators |
Power, Excursion Limit, Thermal (RMS) Limit, Input Clip, Activity |
|
Enclosure Materials |
Multiply 15mm Birch Plywood |
|
Stacking Feature |
Interlocking Rubber Feet (Sides) |
|
Covering / Finish |
Paint |
|
Dimensions (DWH xbackW, inches) |
36.625 (including Casters) x 17.750 x 35.250 |
|
Dimensions (DWH xbackW, cm) |
93 x 45 x 82 |
|
Weight (lbs/kg) |
165/74.9 |
Distribué par Major Audio
