Fiche technique
- Fabricant : Warwick
- Modèle : CCL ND 4
- Série : CCL
- Catégorie : Combos Basse
- Autres dénominations : ccl nd 4, cclnd4, ccl nd4
| Input | 25 mV |
| Preamp | transistor |
|
Power Amp |
fan cooled |
|
Equalizer |
Bass, Punch, Param Mid, Attack, Treb, Lo/Hi Boost |
| Limiter | adjustable |
| Headphone | min 200 ohms |
| Effect Loop |
mono serial send 0 dBu, 600 ohms return 0 dBu, 10kohms |
| Rear Control | Horn Attenuator |
| Nominal Power | 300W / 4 ohms |
| Speaker | Neodymium 15", HF Horn |
| THD | < 0.1% |
| Connectors | Tuner Out, DI Out (pre/post) |
| Switches |
Limiter, Mute, Ground Light, Subsonic, DI Pre/Post |
| Weight (Net / Gross) | 26 / 33 kg |
| Dimensions | 531 x 484 x 601mm |
»
