YannLu EQ-500 (single ou paire)

Description

L'EQ de "Thriller", "Graceland" et bien d'autres ! Un module qui passe sous les radars, sans doute parce qu'il n'est pas très cher... mais ça vaut largement les NEVE, API etc...

The EQ-500 is a monophonic semi-parametric 500-series equalizer inspired by the Harrison MR-4 console (1980), delivering a precise, and transparent sound. Whether you're recording or mixing, this versatile EQ excels at shaping a wide range of sound sources with clarity.

The low and high bands feature selectable shelving or bell curves (proportional Q), offering flexible tonal shaping. The midrange offers three different bandwidths, providing precise control over the equalizer. Each band, along with the high-pass filter, includes an individual bypass function, providing full flexibility in your sound shaping.

The high frequencies are particularly smooth, adding sweetness and clarity without harshness. Whether enhancing vocals, acoustic instruments, or any other source, the EQ-500 delivers a silky, musical top end that complements the rest of your mix perfectly.


- Transformerless
- Through-hole quality components
- Proportional Q
- High-Pass filter : 26 Hz to 2.2 kHz (12dB/oct)
- Low frequency band : 40 Hz to 800 Hz – Bell (2 widths) or Shelf mode
- Mid frequency band : 400 Hz to 8 kHz – 3 bell modes : Narrow / Standard / Wide
- High frequency band : 800 Hz to 15 kHz – Bell (2 widths) or Shelf mode
- Maximum 15 dB of boost/cut gain per band (center detent on 0 dB)
- Bypass switch on each section
- Bi-color LED indicator for signal and clipping (with internal trimmable thresholds)
- Power LED
- Max consumption : 150 mA
- Max Output Level : +23 dB


2 unités disponibles, 390€ / unité.
Visibles entre Toulouse et Albi.
