Fiche technique
The T-Rackonizer is the Eurorack version of the T-Resonator analog filter matrix module.
- 2 analog T-ladder moog-like filters and a digital delay. 24 dB pole lowpass filter transistor cascade.
- 8 different algorithms, each with different delays, wave guides or structures and different feedbacks and modulate them even with an LFO. Delays reach from less than a millisecond to 1 second
- analog feedbacks can delay themselves and thereby form new sound patterns.
- filter controls: cutoff, resonance
- can be feedbacked negatively or positively to itself or even across the partner filter by the mix knobs. Also they can be feedbacked across a digital delay/reverb chip which is literally woven into the signal path.
- sine LFO gets retriggered by the audio signal and can be shaped with the audio envelope or just run alone.
- In center position the amount is 0, to the left it's envelope-shaped LFO, to the right it's only LFO.
- external CV inputs work from 0 to 5 volts.
- Feedback and cutoff controls can be CV-controlled.
- adjustable gain and a Hi-Z input to plug in a guitar directly. Any line level signal can be processed, be it either mono or stereo.
»
