réactions à la news Le papa du Malevolent sort un nouveau synthé !

Un peu plus cher

Duophonic Hybrid-Analogue Synthesiser

• 200 Patches
* All patches in RAM so can be overwritten
* Bank A: 100 Factory presets
* Bank B: 100 User presets (all set to initial patch)
* Compare function
* Initialise patch function

• Duophonic with 2 analogue signal paths
* Mathematically generated oscillators designed by Chris Huggett
* Analogue signal path designed by Chris Huggett

• 2 Oscillators plus sub-oscillator per voice
* Sine / Triangle / Saw / Pulse plus additional wave types
* Shape control and shape modulation input
- Will create pulse width modulation on the pulse waveform with perfect square
at the centre
* Pitch modulation control
* Octave selects per oscillator
* OSC 1 SUB follows oscillator 1 parameters
• Oscillator Drift
* Creates random pitch variations between oscillators

• Multi-mode state variable VCA filters with overdrive
* 2 Analogue filters - 1 per signal path
* Low Pass / Band Pass / High Pass in 12dB and 24dB configurations
* Additional WBAND (series) and WSTOP (parallel) types
* Filter Cutoff
* Filter Cutoff Modulation
* Filter Resonance
* Filter Width
* Filter Width Modulation
* Filter Keytrack

• LFO (Low Frequency Oscillator)
* 2 LFOs
* 4 waveshapes per oscillator
* Fade In / Fade Out parameter
* SYNCable
* Rate control

• Envelopes
* 2 Independent envelopes
* ENV 1 normalised to amplitude
* ADSR
* + Sustain Fall parameter for shaping during key-down
* + Repeat which can be used to create looping envelopes
* Velocity positive and negative control

• Ring modulation
• Mixer
* First mix: OSC1 and OSC2
* Second mix: OSCillators and noise
* Third mix: OSCillators + noise and Ring modulator

• VCA (Voltage Controlled Amplifier)
* All amplification is done in the analogue domain in multi-stage VCAs

• Modulation Routes
* Control - 6 choices of modulation parameters
* Source - 6 choices of effectors from envelopes and LFOs
* Scale - choices of controls used to scale the effect of the modulation

• Glide
* Glide amount
* Auto-glide mode

• Indicator LEDs
* Two LEDs for Voice
* LED for Keyboard activity

• Master tune
• Master volume
• Triggering
* ENV 1 Legato
* ENV 2 Legato
* LFO Keytrig
* LFO Keytrig

• CONNECTIONS
* Master power switch
* DC 9V input
* USBC
* MIDI IN / OUT / THRU
* Sustain pedal input (switch)
* Pedal input (continuous)
* Stereo 1/4” line Outs: L/Mono and R
* Stereo 1/4” headphone out

• Multi-function Joystick control
* Left / right for pitch bend
* Performable vibrato
* Latching hold mode

• Arpeggiator
* 6 arpeggiator types
- Up, Down, Up/Down 1, Up/Down 2, Played & Random
* Sync rates control from 2nds to 32nds
* Tap tempo button
* Swing including positive and negative swing
* Auto clock sync
- Detects MIDI or USB-MIDI clock and synchronises the arpeggiator
automatically
* Latch via joystick HOLD
* 6 Octave range

• Dedicated tempo control
• Duophonic mode control
* Duo mode
* Duo mode with simple filter
* Pan control for duophonic voicing

• Digital Effects
* Reverb time
* Reverb level
* Reverb High Pass Filter
* Reverb Low Pass Filter
* Chorus level
* Chorus type

• Keyboard Control
* 37 Full-size semi-weighted velocity-sensitive keys
* Channel aftertouch
* Octave shift

• Weights and Dimensions (product unboxed)
* 620 x 320 x 110 mm
* 5.3 kg

Includes:
* Power Supply (9V 600mA)
* USB C lead
* Getting Started Guide

Pricing MSRP:
* US: $1,499
* EUR: €1,599 inc. VAT
* UK: £1,349 inc. VAT

x

Hors sujet :

2 oscil­la­teurs numé­riques géné­rés mathé­ma­tique­ment et déri­vables, conçus par Chris Huggett, et un sub par voix, avec des contrôles de la forme de l’onde, de la modu­la­tion du pitch, et de l’oc­tave

Chris Huggett ? Chapeau ! jusqu'au bout un passionne.
