the modules;
The time scape section is the main brain for timing of all of the rest of the impossible box time-based modules. It's a sampler with six clock outputs. Any of the clock outs can be sent to the clock multipliers.

There are two clock multipliers that output voltage to run any/all of the;
- 4 ADSR's
- 4 relay based sequencers (used to alter the time scape sample, trigger drums or on/off switches)
- 2 CV based sequencers used to trigger;
= analog drums (clicky, poppy, bassy goodness)
- 3 CV based sequencers used to control;
= any of 6 oscillators (3 sine, 3 square)
= any of four ADSR's
= any of three filters
= the timing of any of 3 digital delays
= or all of the above

- Two pitch shifters, each of which is drastically different, one of which becomes a sampler.
- A harmonizer
- three reverbs with multiple styles
- a four track looper
- phaser
- independant looper and analog delay
- digital drum with trigger outs and a piezo panel for finger drumming
- intelligent modulator that slices things up in brilliant ways
- 2 dumb modulators that slice things up in simple ways or send CV
- multiplier/audio vactrol control panel
- 4 ADSR's (as mentioned) that send CV but also take direct audio
- Midi clock out (accepts pulse from time scape)
- 2 mixers (one 4 channel mono, one 8 channel stereo)

and the amplified acoustic panels;
- 2 thumb pianos,
- single string slide-based thing
- a blank panel to scratch at or set things that make sound on.
- and finally...a melodica (yes...that's fuckin right)

Though audio patching can be done with 1/4" jacks (which I prefer) there is also a main patch panel that has most ins and outs in one place for direct complex patching.
Any external audio can be sent into just about anything.
